HANA LPG injector strip 3cyl H2002 red

HANA H2002 TYPE B red version of 3-cylinder, the injection strip, thanks to its simple and proven design, is characterized by high resistance to contaminants present in LPG gas. The injector is designed for automotive LPG sequential gas injection systems.

Technical data:

• Maximum output: 39 hp/cyl.
• Coil resistance: 1.9Ohm
• Voltage: 12V DC
• Opening time: 2.0ms
• Closing time: 1.2ms
• Maximum working pressure: 4.0bar
• Input spigot: 6mm
• Output spigot: 6mm
• Plug: Superseal / Valtek
• Operating temperature: -40°C ÷ 120°C
